CAPABILITY | STANDARD | ADVANCED |
MinimumLayer Count | 1 | 1 |
MinimumLayer Count | 12 | 24 |
| FR-4 (Tg-135C, 145C, 170C), Halogen- free Rogers Ultralam 2000, Rogers RO4350, Rogers RO4003
Polyimide
Black FR-4
Arlon AR-350
CEM-3
Getek Copper Clad Thermal Substrates
Hybrid (Rogers and FR4) BT Epoxy
Nelco 4013
PTFE
Metal Core Materials
Aluminum Core |
Board Thickness | 0.020"-0.125" | 0.005"-0.250" |
| 16" x 22" 12" x 21" 22" x 28" | 10" x 16"
16" x 22"
12" x 21"
22" x 28" |
Copper Thickness | 0.5 oz – 3 oz | 0.25 oz – 12 oz |
Minimum Trace Width / Spacing | 0.004"/0.004" | 0.003"/0.003" |
Solder Mask Color | Green, Blue, Black, Red, Yellow, White, Clear, and customized |
Silkscreen Color | White, Black, Yellow, Green, Red, Blue and customized |
Minimum Hole Size | 0.008" | 0.004" |
Finished Hole Size Tolerance | +/-0.003" | +/-0.002" |
| HASL (vertical & Horizontal), Lead Free HASL, OSP/Entek, ENIG,
ENEPIG, HASL + Gold Finger,Immersion Tin(ISn), Immersion Silver(IAg),
Carbon
Ink, Hard Gold(Flash Gold), Soft Gold
|
IPC Class | Class 2 | Class 3 |
Controlled Impedance Tolerance | +/-10 % | +/-5 % |
Blind Vias | Yes | Yes |
Buried Vias | Yes | Yes |
Aspect Ratio | 8/1 | 15/1 |
Minimum Core Thickness | 0.004" | 0.002" |
Carbon Ink | Yes | Yes |
Peelable Mask | Yes | Yes |
Solder Sample | Yes | Yes |
First Article | Yes | Yes |
ISO 9001: 2008 | Yes | Yes |
ISO/TS16949: 2009 | Yes | Yes |
UL 94v0 | Yes | Yes |
Company Information:
Global Well Electronic Inc. is a professional PCB solution supplier
from Shenzhen, China, integrating PCB circuit board production and
processing, STM processing and mounting, PCBA OEM, component
purchasing, PCB/PCBA custom design-production- A comprehensive PCB
circuit board company with one-stop turnkey service of
processing-assembly-finished products. The company has a strong
supply chain system, a professional and efficient collaborative
team, a sound and complete quality control system, and the business
philosophy of honesty and trustworthiness, customer first, and
presents the products to everyone with low prices, reliable
quality, high-quality service and after-sales service. client.
We provide total PCB solutions from PCB design to final mass
production, including PCB fabrication and assembly, component
sourcing, solder paste stencils, conformal coatings, and more.
Serving the global electronics field, including industrial control,
medical electronics, military equipment, power communication,
automotive electronics, AI artificial intelligence, smart home and
other industries.
Factory Produced:
Our Capacit:
| PCB Assembly Capability |
| Order Quantity | 30000 Square Meter/Square Meters per Month module electronic
board(including prototype) |
| Components | SMD and THT
From size 0402.0201 to 01005
SOIC,PLCC,TSOP,QFP,BGA |
| Assembly Method | Single and double-sided/SMD and THT/SMT and Thru-hole |
| Ball Grid Array(BGA) | As small as 0.5mm pitch
All BGA placements are inspected by X-Ray |
| Components Package | Poles,Reels,Tape Strips,Bulk Supply |
| Maximum Componentsize | 55*55*15mm
Fine Pitch from 0.4mm
Minimum Pin width 0.2mm |
| Solder | Lead free and conforming to DIN 32513,ISO,EN29454,IPC 650 |
| Related Test | Aol & X-Ray Inspection,Flying Probe Test and in Circuit Test |
| File Format | BOM & Gerber files |
FAQ
1.Which type of PCBs do you expert in?
We are specialized in producing Singe-side PCB,Double-side PCB,
Multilayer PCB,Aluminium PCB,Spray Tin PCB,Immersed Gold PCB, etc.
2.What is your Lead time?
Lead time is usually punctual here, usually 5-10 days for PCB
sample, 10-15 days for mass production. For some special situation,
we can also advise customer in advance to avoid any inexpectation
or loss at customer side.
3.What is your testing policy and how you controle the quality?
For sample, usually tested by flying probe; for PCB Volume over 3
square meters, usually tested by fixture, this will be more faster.
Due to there’s many steps to PCB production, we usually do
inspection after every step.
4.PCB shipment?
This is depend on customer, sometimes we ship through our
forwarder, who is also the agency of DHL, TNT, UPS, Fedex, and so
on. Our forwarder can provide too much better freight cost than we
get directly from those express enterprise.
5.I only have the pcb sample, not pcb file, can you produce it for
me?
Yes, we can copy file based on your sample, this file names gerber,
and production then is accorded to gerber file.
6.What kind of PCB file format can you accept for production? What
CAM software do you use?
We accept Gerber file for production. CAM350, GENESIS, UCAM,
GC-CAM, V-2000.
7.Will you allow me to put several part number together into one
panel?
Yes, this is usually happen in we factory, this way can help
customers reduce some cost and to a certain degree, it can help
reduce some assembly cost.
